Full Automatic Pyramid Tea Bag Packing Machine with Outer Envelope is used for automatically packing products as green tea ,black tea, flower tea ,health tea, medicine tea, granule and so on .
Main Functions of Pyramid Tea Bag Packing Machine
- This unit can perform either three sides sealing and triangle pyramid teabag .just need single bond to change the bag between three sides sealing and triangle pyramid shape.
- packaging capacity: 3000bags/h (Determined by packing material)
- Applicable packing materials:Nylon film with thread and label.
- The precision volumetric metering way very easily in the transformation of filling material. Electronic scale metering can be collocated according to the material.
- Human-Computer Interface, Omron PLC control, adopted the Panasonic double Servo motor to make the bag , supplied complete setting functions.easy operating
- Main motor overload protection device
- Packaging material tension automatic adjustment device
- The machine will automatically stop when Issued the warning.
Advantages Feature of Pyramid Tea Bag Packing Machine
- Pyramid Tea Bag Packing Machine adopts flat bags packing, triangle pyramid tea bags packing and so on format to do packing!
- the whole machine can finish the whole process automatically: material feeder-measuring(double head electronic scale)- bags making-sealing-cutting-counting-finish products conveyor.
- the machine adopts high precise control system to adjust the whole machine working, with compact structure, computer controller, easy operation system, and easy maintenance.
- adopts servo motor, which makes the machine bag length stable, positioning precise, adjusting easily.
- using ultrasonic sealing, and electronic scale filling, sealing tight and filling accurate.
- the machine equipped with packing material strength adjusting automatically device.
- the machine have automatic alarming and stopping function.
Specification of Pyramid Tea Bag Packing Machine
| Capacity | 30-40bags/Min (Determined by packing material) |
| Filling precision | ≤±2% (Determined by packing material) |
| Bag size | 60-80(W)*40-80(L)mm |
| Packing film | 120mm,140mm,160mm |
| Sealing type | Triangle bag and flat bag |
| Filling range | 2-10ml |
| Film thickness | 0.04-0.06mm |
| Packing material | Nylon, Polyester net non-woven fabrics,. ultrasonic sealing materials |
| Rolled outer diameter | ≤400mm |
| Rolled paper core inside diameter | 76mm |
| Air consumption | 0.6Mpa 0.4m3/min |
| Total power | 2.2KW |
| Power | Single 220V 50HZ |
| Air compressor | less than 1 cube |
| Dimension | 1200*920*2060mm |
Working Video of Double Weigher Head Pyramid Tea Bag Packing Machine
